Key Features

• Maximum Readers
  • Up to 2 Readers (Wiegand and/or RS-485)
• Maximum Doors
  • 2
• Maximum Users
  • 10,000
• Event Buffer
  • 1,00,000
• Interface
  • EthernetwithPoE
• Standalone Mode
  • With Built-In Software in COSEC PANEL LITE
• Network Mode
  • With COSEC CENTRA with or without PANEL LITE
• Connections
  • DATA0, DATA1, LED0, LED1, BUZZER, Tamper, Power, GND, RS-485A, RS-485B
• Power
  • 12V DC at Max. 150mA per Reader
• Reader Types
  • 2 Reader Port for any Wiegand or Matrix Reader
• Interface
  • Wiegand and RS-485 (For Matrix Reader Only)
